Bringing Your VMs to Kubernetes With KubeVirt

Kubernetes
April 6, 2021

This article is dedicated to the open source project KubeVirt.io, which allows you to bring your virtual machine workloads to Kubernetes. A second part will explain how to use it with Kubermatic Kubernetes Platform.

What Is KubeVirt?

KubeVirt allows your virtual machine workloads to be run as pods inside a Kubernetes cluster. This allows you to manage them with Kubernetes without having to convert them to containers.

Why Do We Need KubeVirt?

Do you have a project running in VMs which you don’t want to convert to containers? Perhaps because it’s a legacy project for which you don’t want to go through the effort and expense of converting, but you’d like to orchestrate them with Kubernetes anyway?

Do you have a project for which you require the special features of VMs?

In these cases, KubeVirt is the answer for you!

Trying It Out

This tutorial will guide you through the installation of KubeVirt with Minikube. Minikube allows you to run Kubernetes on your local computer. A second part will show you how to use KubeVirt with Kubermatic Kubernetes Platform.

Install minikube

First, you have to follow the installation instructions to install minikube. Then start it with:

minikube start

You should see this output:

😄  minikube v1.17.1 on Darwin 11.2.3
✨  Using the docker driver based on user configuration
👍  Starting control plane node minikube in cluster minikube
🚜  Pulling base image ...
💾  Downloading Kubernetes v1.20.2 preload ...
    > preloaded-images-k8s-v8-v1....: 491.22 MiB / 491.22 MiB  100.00% 3.84 MiB
🔥  Creating docker container (CPUs=2, Memory=1989MB) ...
🐳  Preparing Kubernetes v1.20.2 on Docker 20.10.2 ...
    ▪ Generating certificates and keys ...
    ▪ Booting up the control plane ...
    ▪ Configuring RBAC rules ...
🔎  Verifying Kubernetes components...
🌟  Enabled addons: storage-provisioner, default-storageclass
    ▪ Want kubectl v1.20.2? Try 'minikube kubectl -- get pods -A'
🏄  Done! kubectl is now configured to use "minikube" cluster and "default" namespace by default

You can use kubectl as usual in minikube, but you have to preface any command with minikube and put a – after kubectl. Example: the regular kubectl get pods becomes minikube kubectl -- get pods.

Enable Addon

Now you have to enable the KubeVirt addon:

minikube addons enable kubevirt
- Using image bitnami/kubectl:1.17
* The 'kubevirt' addon is enabled

You can now use KubeVirt! Check if the resources have been created correctly:

minikube kubectl -- get all -n kubevirt

You should see 7 pods, 3 services, 1 daemonset, 3 deployment apps, and 3 replica sets. It might take some time for all the objects to be ready and running.

NAME                                  READY   STATUS    RESTARTS   AGE
pod/virt-api-6bb566bbc7-crspt         1/1     Running      0       28m
pod/virt-api-6bb566bbc7-fh5jg         1/1     Running      0       28m
pod/virt-controller-5d6975c644-j4mbp  1/1     Running      2       28m
pod/virt-controller-5d6975c644-r6w7r  1/1     Running      3       28m
pod/virt-handler-brxxs                1/1     Running      2       28m
pod/virt-operator-976969b94-hsrpb     1/1     Running      2       30m
pod/virt-operator-976969b94-k78wh     1/1     Running      2       30m



NAME                                 TYPE        CLUSTER-IP     EXTERNAL-IP   PORT(S)   AGE
service/kubevirt-operator-webhook    ClusterIP   10.102.7.174   <none>        443/TCP   28m
service/kubevirt-prometheus-metrics  ClusterIP   10.102.43.88   <none>        443/TCP   28m
service/virt-api                     ClusterIP   10.111.29.61   <none>        443/TCP   28m



NAME  	                     DESIRED   CURRENT   READY   UP-TO-DATE   AVAILABLE
daemonset.apps/virt-handler    1         1         1        1             1
NODE                         AGE
kubernetes.io/os=linux       28m



NAME                                  READY    UP-TO-DATE   AVAILABLE   AGE
deployment.apps/virt-api               2/2         2            2       28m
deployment.apps/virt-controller        2/2         2            2       28m
deployment.apps/virt-operator          2/2         2            2       30m



NAME                                        DESIRED   CURRENT   READY    AGE
replicaset.apps/virt-api-6bb566bbc7          2          2         2      28m
replicaset.apps/virt-controller-5d6975c644   2          2         2      28m
replicaset.apps/virt-operator-976969b94      2          2         2      30m


NAME                           	            AGE       PHASE
kubevirt.kubevirt.io/kubevirt   	    30m       Deployed

Install virtctl

Run the following to install virtctl, a tool to explore graphical ports of the VM:

VERSION=$(kubectl get kubevirt.kubevirt.io/kubevirt -n kubevirt -o=jsonpath="{.status.observedKubeVirtVersion}")
ARCH=$(uname -s | tr A-Z a-z)-$(uname -m | sed 's/x86_64/amd64/') || windows-amd64.exe
echo ${ARCH}
curl -L -o virtctl https://github.com/kubevirt/kubevirt/releases/download/${VERSION}/virtctl-${VERSION}-${ARCH}
chmod +x virtctl
sudo install virtctl /usr/local/bin

Create a VM Resource

Now create a file locally named vm.yaml, then copy and paste the below configuration into the file. Use minikube kubectl create -f vm.yaml to create the VM resource on the cluster:

apiVersion: kubevirt.io/v1alpha3
kind: VirtualMachine
metadata:
  name: testvm
spec:
  running: false
  template:
    metadata:
      labels:
        kubevirt.io/size: small
        kubevirt.io/domain: testvm
    spec:
      domain:
        devices:
          disks:
            - name: containerdisk
              disk:
                bus: virtio
            - name: cloudinitdisk
              disk:
                bus: virtio
          interfaces:
          - name: default
            bridge: {}
        resources:
          requests:
            memory: 64M
      networks:
      - name: default
        pod: {}
      volumes:
        - name: containerdisk
          containerDisk:
            image: quay.io/kubevirt/cirros-container-disk-demo
        - name: cloudinitdisk
          cloudInitNoCloud:
            userDataBase64: SGkuXG4=

Alternatively, you can download the manifest directly from Github using:

wget https://raw.githubusercontent.com/kubevirt/kubevirt.github.io/master/labs/manifests/vm.yaml

Then apply it to the cluster using the command:

minikube kubectl -- apply -f https://raw.githubusercontent.com/kubevirt/kubevirt.github.io/master/labs/manifests/vm.yaml

virtualmachine.kubevirt.io "testvm" created
virtualmachineinstancepreset.kubevirt.io "small" created

Use kubectl get to check the VM status:

$ kubectl get vms

NAME     AGE   VOLUME
testvm   12m

You can get more information about the created “testvm” using:

$ kubectl get vms -o yaml testvm

Starting a Virtual Machine

You can start a virtual machine by using virtctl:

./virtctl start testvm

Alternatively, you can use kubectl patch:

    '{"spec":{"running":true}}'

Check if the virtual machines are running:

minikube kubectl -- get vms

NAME       AGE    RUNNING   VOLUME
testvm       5s          false

Peradventure the “Running” column is missing, you can use kubectl describe to check if the VM is running. The output will look like this:

$ kubectl describe vm
Spec:
  Running:  true
  Template:
    Metadata:
      Creation Timestamp:  <nil>
      Labels:
        kubevirt.io/domain:  testvm
        kubevirt.io/size:    small

Now that the vm is running, you can check the status. The status could come in three phases which are:

$ kubectl get vmis

NAME       AGE    PHASE          IP         NODENAME
testvm     50s    Scheduling
$ kubectl get vmis

NAME      AGE     PHASE          IP         NODENAME
testvm    3m43s   Scheduled                 minikube
$ kubectl get vmis

NAME      AGE     PHASE          IP         NODENAME
testvm    14m     Running    172.17.0.11    minikube

Scheduling: This is the beginning of the phases where the VM components are provisioned.

Scheduled: The status changes to “scheduled” after a few minutes which also signals that the node is ready by outputting the node name.

Running: This is the final stage where all the components have been provisioned by outputting the IP address.

As seen above, you are able to access your virtual machines with kubectl just like you would be able to with pods.

Clean-Up: Shutdown and delete To stop your virtual machine run:

./virtctl stop testvm


VM testvm was scheduled to stop

To delete the VM entirely, execute:

virtualmachine.kubevirt.io "testvm" deleted

Stop minikube after you are done with the tutorial: minikube stop

Delete minikube: minikube delete –all

Conclusion

This is the first part of this blog post. The next part will guide you through using KubeVirt with Kubermatic Kubernetes Platform.
