Running HA Kubernetes clusters on AWS using KubeOne

In a previous blog post, we talked about KubeOne and how it makes your highly available Kubernetes cluster easier to manage. In this post, I’ll show you step-by-step how to deploy and run a vanilla cluster with machine-controller and metrics-server on AWS. You may also adapt this process to other providers since it differs only marginally.

Creating your first cluster

In this example we use Terraform to create the infrastructure. Of course KubeOne can also be configured using Ansible or manually. We will need to run through the following steps:

  • Get KubeOne and Terraform
  • Create infrastructure
  • Create configuration file
  • Install your cluster using KubeOne
  • Enjoy and have fun

If this sounds like much effort: Don’t worry, we have taken care of many steps for you. Expect about 20 minutes of your time for these steps.

How to AWS?

Let’s say you just have access to Amazon Web Services (AWS) and you want to get started, go ahead and grab the latest release on our releases page. We support KubeOne on Linux and MacOS.


Starting with v0.10.0-alpha.0, our release archive contains the KubeOne binary and example Terraform scripts that can create the infrastructure for you. If you want to use an earlier version you may find the examples in our GitHub repository. If you got a distribution with up to date package repositories you can fetch Terraform that way, otherwise follow their installation guide (Take at least version 0.12.0).


Next up, we’ll configure Terraform and create the infrastructure where we’ll run Kubernetes. Inside the KubeOne repository, head into the examples/terraform/aws directory. Here you’ll find a Terraform scripts you can use to get started.

First, fetch the required Terraform modules using the following command:

terraform init

If you don’t need anything too fancy, you don’t need to touch the existing files here. You just need to create a file named `terraform.tfvars` that contains basic information on how your cluster should be shaped:
cluster_name = "alexbox"
aws_region = "eu-central-1"
worker_os = "ubuntu"
ssh_public_key_file = "~/.ssh/"

This sets the name of the new cluster, the region where nodes will reside in and the flavor of the worker nodes. I chose the region of Central Europe (since I live here and want short latencies) and Ubuntu for control plane and worker nodes. By default a single worker node is created initially. Terraform will copy your public SSH key to created hosts so you can access them. Make sure that it is present at the configured location. There are more options you can customize, just take a look into `` for a list of variables.

To tell Terraform and KubeOne how to authenticate, export your credentials (note that the first character of the command line is a space, which prevents your credentials from popping up in your bash history):


This credentials are also deployed on the cluster so tools like machine-controller can autoscale your cluster.

If you want to customize the initial infrastructure state even more , e.g. increase the amount of worker nodes, you can edit the file accordingly. Finally, create you infrastructure using:

terraform apply

Now that our infrastructure is in place, in comes KubeOne, which will set up the cluster for us.

Deploy your K8s high up in the clouds

Now you have some barren VMs that need to be populated with your hopes and dreams, mainly the Kubernetes control plane. Use the following command to generate a KubeOne configuration file:

$ kubeone config print > config.yaml

In our case, the configuration contains the kubernetes version to install and which cloud provider to use. The rest is taken over from the Terraform configuration:
kind: KubeOneCluster
name: alexbox
  kubernetes: 1.14.1
  name: aws

The basic KubeOne configuration file defines what Kubernetes version will be used and on what provider we’re deploying on. The configuration file has many more options and features and if you want to customize them, get the full config file with
$ kubeone config print --full > config.yaml

The cluster provisioning is done by supplying the `install` command with the config file and the Terraform state.
$ kubeone install config.yaml -t .

#### Using your newly created cluster And now that the cluster provisioning is done, you can use your new cluster. KubeOne even dropped the kubeconfig file for your. Just export its location as an environment variable with:
$ export KUBECONFIG=$PWD/alexbox-kubeconfig

You are ready to `kubectl` around as you like. For example, try out to list nodes of the new cluster:
$ kubectl get nodes

#### Scaling your cluster KubeOne installs a vanilla cluster with a couple of open source projects, such as [machine-controller](, for automatically managing the cluster using Cluster-API and [metrics-server.]( Machine-controller makes it easy to scale your cluster on demand. Execute the following to get all MachineDeployments in your new cluster:
kubectl --kubeconfig=alexbox-kubeconfig get -n kube-system machinedeployment

The result should be something like this:
NAME                REPLICAS         PROVIDER        OS                   KUBELET AGE
alexbox-pool1       1                aws             ubuntu 1.14.1        3m44s

To increase the number of worker nodes to three just scale the machine deployment up:
kubectl scale -n kube-system machinedeployment/alexbox-pool1 --replicas=3

**Note:** There is currently a [bug]( with Kubernetes 1.15 requiring you to provide the resource version when using the `scale` command. This version can be obtained using `kubectl describe`.

Of course you can also configure to opt-out of machine-controller but you would have to take care of worker nodes by yourself.


As you can see, the happy path of KubeOne makes bootstrapping a cluster much more automated, less error prone and (almost) fun to do.

KubeOne works out-of-the-box with a bunch of other cloud providers including Google Cloud, Packet and DigitalOcean. You can even install a cluster on premise with OpenStack, VMware vSphere or completely bare metal if you are adventurous. See our docs for more information, take a look at our latest webinar or the technical deep-dive talk that was recorded on the ContainerDays 2019.
